PFERD 79181704

PFERD 79181704 by PFERD

Call For Price
  • Part Number: 79181704
  • UPC:
  • Availability:
Quantity:
Add To Quote
Add To Estimate
Add To Wishlist
Compare Item
Product Overview
Info & Guides
PFERD Standard Twist Knot Wire Wheel Brush 8" Dia. .016 Carbon Steel 5/8" Arbor
Long Description
The brush knots are knotted to 75% of the length. The brush is designed for brushing large areas and for heavy-duty brushwork, such as deburring, cleaning, derusting and descaling, as well as removing spatter. Steel wire is the most common filament material. Brushes with steel wire as the filament material are ideal for work on surfaces and deburring. PFERD special wire has high tensile strength and bending fatigue strength. This ensures that the wire wears down in the optimal way, as well as a long tool life, even in extreme brushing applications. Steel wire is temperature-resistant up to 600°F.
Specifications
Details
Advantages:
Optimal ratio of aggressiveness and flexibility.
Advantages 1:
Long service life through use of PFERD special wire.
Applications:
Cleaning
Applications 1:
Deburring
Applications 2:
Derusting
Applications 3:
Descaling
Applications 4:
Removing oxide layers
Applications 5:
Paint stripping
Applications 6:
Root seam processing
Applications 7:
Work on weld seams
Applications 8:
Work on fillet welds
CONTENT_UNIT:
C62
COUNTRY_OF_ORIGIN:
US
DEPTH:
0.216
Dia. external:
8
Dia. external UNIT:
Inch
Dia. filament material:
0.016
Dia. filament material UNIT:
Inch
Dia. hole:
5/8
Dia. hole UNIT:
Inch
Drive types:
Stationary machines
EAN pcs.:
4007220513514
EAN type:
AR
Filament material:
Steel wire (ST)
Gross weight (Piece):
1.03
Gross weight (Piece) UNIT:
kg
Height (Packaging unit):
216
Height (Packaging unit) UNIT:
mm
Installation width:
5/8
Installation width UNIT:
Inch
INTERNATIONAL_PID (ean):
4007220514283
INTERNATIONAL_PID (edp):
81704
INTERNATIONAL_PID (gtin):
4007220514283
KEYWORD:
Industrial power brushes
KEYWORD 1:
Wheel brushes
KEYWORD 2:
Knotted / standard twist, standard flag
KEYWORD 3:
With hole
LEADTIME:
3
LENGTH:
0.216
Length (Packaging unit):
216
Length (Packaging unit) UNIT:
mm
MANUFACTURER_NAME:
PFERD
MANUFACTURER_PID:
79181704
MANUFACTURER_TYPE_DESCR:
8" STD TW KT WHL .016CS 5/8AH
Materials that can be worked:
Cast iron
Materials that can be worked 1:
Cast steel
Materials that can be worked 2:
Steel, cast steel
Materials that can be worked 3:
Steel materials with a hardness > 54 HRC
Materials that can be worked 4:
Steels up to 370 HV (< 38 HRC)
Mounting system:
Centre hole
NO_CU_PER_OU:
1
Number, knots:
42
Number, knots UNIT:
Stück
ORDER_UNIT:
C62
Output name <= 80 characters:
PFERD Standard Twist Knot Wire Wheel Brush 8" Dia. .016 Carbon Steel 5/8" Arbor
Packaging:
Industrial packaging
Product issue name web for bmecat:
Wheel brushes knotted, standard twist, standard flag with hole
PRODUCT_ORDER:
190
prop65:
Warning: Cancer and Reproductive Harm -- www.P65Warnings.ca.gov
QUANTITY_INTERVAL:
2
QUANTITY_MIN:
2
Recommendations for use:
Please observe the recommended rotational speeds.
REFERENCE_FEATURE_GROUP_ID:
P_16322_184955
RPM, max.:
7000
RPM, max. UNIT:
RPM
RPM, optimum, from:
3500
RPM, optimum, from UNIT:
RPM
RPM, optimum, to:
5000
RPM, optimum, to UNIT:
RPM
SPECIAL_TREATMENT_CLASS:
Warning: Cancer and Reproductive Harm -- www.P65Warnings.ca.gov
TIME_BASE:
dayofweek
TIME_VALUE_END:
5
TIME_VALUE_START:
1
Trim length:
1 5/8
Trim length UNIT:
Inch
UNSPSC 25.0901:
27111907
UPC pcs.:
0
VOLUME:
0.002589
Volume (Packaging unit):
2589
Volume (Packaging unit) UNIT:
CCM
WEIGHT:
1.03
WIDTH:
0.216
Width:
5/8
Width (Packaging unit):
216
Width (Packaging unit) UNIT:
mm
Width UNIT:
Inch
Manufactured By:
PFERD
