Part Number: 69220606 / Vendor ID #: 1139477
PFERD 69220606
by PFERD
Call for Price
Item Sales Info
Add To Wishlist
Compare Item
Email
Print
Availability
- Manufacturer availability unknown.
Dimensions
Info & Guides
PFERD Grinding Wheel, 5" x 1/8 x 5/8-11, ZIRKON SG CAST+STEEL, T27, ZA, AO
The wide range Performance Line SG offers high-performance solutions for every application and material. Performance Line SG products achieve optimum results with excellent economic efficiency. For heavy-duty use in foundries and fettling shops, PFERD offers particularly robust grinding wheels that have maximum safety and achieve top performance, even under these conditions. They are optimized for use on compressed-air turbine and high-frequency angle grinders. Zirconia alumina grinding wheel designed for use on cast iron and steel in foundries and fettling shops. Excellent grinding performance and very good service life.
Abrasive:
ZA
Advantages:
Very fast work and high economic efficiency due to the high grinding performance.
Advantages 1:
Very good durability.
Applications:
Chamfering
Applications 1:
Deburring
Applications 2:
Grouting
Applications 3:
Surface grinding
Applications 4:
Work on weld seams
Applications 5:
Work on fillet welds
CONTENT_UNIT:
C62
COUNTRY_OF_ORIGIN:
ES
DEPTH:
0.197
Dia. external:
5
Dia. external UNIT:
Inch
Dia. hole:
5/8-11
Dia. thread:
5/8-11
Drive types:
Angle grinder
EAN pcs.:
4007220243336
EAN type:
AR
Gross weight (Piece):
0.179
Gross weight (Piece) UNIT:
kg
Height (Packaging unit):
197
Height (Packaging unit) UNIT:
mm
INTERNATIONAL_PID (ean):
4007220745250
INTERNATIONAL_PID (edp):
63256
INTERNATIONAL_PID (gtin):
4007220745250
INTERNATIONAL_PID (upc):
97758632560
KEYWORD:
Grinding wheels
KEYWORD 1:
Performance Line SG ★★★☆
KEYWORD 2:
Foundry grinding wheels
LEADTIME:
3
LENGTH:
0.127
Length (Packaging unit):
127
Length (Packaging unit) UNIT:
mm
MANUFACTURER_NAME:
PFERD
MANUFACTURER_PID:
69220606
MANUFACTURER_TYPE_DESCR:
E 125-4,1 ZIRKON SG CAST+STEEL/H TMNA
Materials that can be worked:
Cast steel
Materials that can be worked 1:
Grey/nodular cast iron (GG/GJL, GGG/GJS)
Materials that can be worked 2:
Steel
NO_CU_PER_OU:
1
ORDER_UNIT:
C62
Output name <= 80 characters:
PFERD Grinding Wheel, 5" x 1/8 x 5/8-11, ZIRKON SG CAST+STEEL, T27, ZA, AO
Product issue name web for bmecat:
Grinding wheels ZIRKON SG CAST+STEEL ★★★☆
PRODUCT_ORDER:
160
prop65:
Warning: Cancer -- www.P65Warnings.ca.gov
QUANTITY_INTERVAL:
10
QUANTITY_MIN:
10
Recommendations for use:
Ideal for work on root seams.
REFERENCE_FEATURE_GROUP_ID:
P_15128_171590
RPM, max.:
12200
RPM, max. UNIT:
RPM
SEGMENT:
Cut-off wheels, flap discs and grinding wheels
Shape:
E / 27 / T27
SPECIAL_TREATMENT_CLASS:
Warning: Cancer -- www.P65Warnings.ca.gov
TIME_BASE:
dayofweek
TIME_VALUE_END:
5
TIME_VALUE_START:
1
UNSPSC 25.0901:
31191600
UPC pcs.:
0
UPC type:
UC
UPC VE:
97758632560
VOLUME:
0.003177
Volume (Packaging unit):
3177
Volume (Packaging unit) UNIT:
CCM
WEIGHT:
0.179
WIDTH:
0.127
Width:
1/8
Width (Packaging unit):
127
Width (Packaging unit) UNIT:
mm
Width UNIT:
Inch
Manufactured By:
PFERD
