For coarse grinding work with a high stock removal rate and cool grinding. Active grinding additives in the coating substantially improve the stock removal rate, prevent loading and result in cooler grinding. In ISO 2421, abrasive spiral bands are designated as "cylindrical sleeves". GSB = bulk pack of abrasive spiral bands
Specifications
Details
Abrasive:
Zirconia alumina Z-COOL
Advantages:
Abrasive spiral bands fit securely on the rubber drum holder as the holder expands during use.
Advantages 1:
Outstanding service life even under the toughest work conditions, due to special manufacturing.
Advantages 2:
Highest possible cost-effectiveness due to particularly high stock removal rate and aggressiveness of the abrasive.
Applications:
Deburring
Applications 1:
Step-by-step fine grinding
Applications 2:
Leveling
Applications 3:
Roughening
Applications 4:
Sharpening
Applications 5:
Surface work
Applications 6:
Work on weld seams
Applications 7:
Working on edges
CONTENT_UNIT:
C62
COUNTRY_OF_ORIGIN:
DE
DEPTH:
0.153
Dia. external:
2 3/8
Dia. external UNIT:
Inch
Drive types:
Flexible shaft drive
Drive types 1:
Straight grinder
EAN pcs.:
4007220315675
EAN type:
AR
Grit size:
80
Gross weight (Piece):
0.013
Gross weight (Piece) UNIT:
kg
Height:
1 1/8
Height (Packaging unit):
153
Height (Packaging unit) UNIT:
mm
Height UNIT:
Inch
INTERNATIONAL_PID (ean):
4007220148600
INTERNATIONAL_PID (edp):
41429
INTERNATIONAL_PID (gtin):
4007220148600
INTERNATIONAL_PID (upc):
97758414296
KEYWORD:
Coated abrasives
KEYWORD 1:
Abrasive spiral bands, cylindrical
KEYWORD 2:
Zirconia alumina Z-COOL version
LEADTIME:
3
LENGTH:
0.263
Length (Packaging unit):
263
Length (Packaging unit) UNIT:
mm
MANUFACTURER_NAME:
PFERD
MANUFACTURER_PID:
42211188
MANUFACTURER_TYPE_DESCR:
GSB 6030 Z-COOL 80
Materials that can be worked:
Annealed cast iron
Materials that can be worked 1:
Bronze
Materials that can be worked 10:
Titanium
Materials that can be worked 11:
Titanium alloys
Materials that can be worked 2:
Cast steel
Materials that can be worked 3:
Cobalt-based alloys
Materials that can be worked 4:
Grey/nodular cast iron (GG/GJL, GGG/GJS)
Materials that can be worked 5:
Hardened, heat-treated steels over 370 HV (38 HRC)
To easily change the abrasive spiral bands, give them a slight clockwise twist and pull them up and off. When doing so, leave the rubber drum holder clamped in the power tool.
Recommendations for use 1:
To ensure the abrasive spiral band is securely attached, follow the minimum speed for the rubber drum holder.
Recommendations for use 2:
For the best performance, use with a recommended peripheral speed of 4,000-6,000 SFPM.
Recommendations for use 3:
Use the appropriate grinding oil for the material to significantly increase the service life and the abrasive performance of the discs.
REFERENCE_FEATURE_GROUP_ID:
P_16010_179768
RPM, optimum, from:
6500
RPM, optimum, from UNIT:
RPM
RPM, optimum, to:
9500
RPM, optimum, to UNIT:
RPM
Safety notes:
The maximum permitted peripheral speed is 6,000 SFPM.
Safety notes 1:
For safety reasons, the maximum permitted rotational speed indicated must never be exceeded.
Safety notes 2:
Do not allow abrasive spiral bands to protrude beyond the rubber drum holder.
