Part Number: 03043617 / Vendor ID #: 11403
SN400R-0.500-E2-H061.0-Z4
by Niagara
Call for Price
Item Sales Info
Add To Wishlist
Compare Item
Email
Print
Availability
- Manufacturer availability unknown.
Dimensions
Specific Products: 03043617
Solid Carbide High Feed High Feed End Mill
Niagara Solid Carbide High Feed High Feed End Mill SN400R-0.500-E2-H061.0-Z4
Category:
Milling
Subcategory:
Solid
Subtype:
Milling Cutters
Coating:
AlTiN
End Type:
High Feed
Material:
CARBIDE
Series:
SN400R
APMX - Maximum Depth of Cut:
0.02 in
APMXE - Maximum Depth of Cut Feed Direction:
0.1 in
APMXS - Max Depth Feed Direction:
0.02 in
Application:
Facing; Slotting; Plunging
Brand Name:
Niagara
CCC- Center Cutting:
No
CCER - Curved Cutting Edge Radius:
0.2485 in
CEDC - Cutting Edge Count:
4
Cmax - Maximum Helical Interpolation Hole Diameter:
0.906 In
Cmin - Minimum Helical Interpolation Hole Diameter:
0.65 in
DC - Cutting Diameter:
0.25 in
DC1 - Cutting Diameter 1:
0.41 in
DCTOLL - Lower Cutting Diameter Tolerance:
-0.0001 in
DCX - Maximum Cutting Diameter:
0.5 in
DMM - Shank Diameter:
0.5 in
DN - Neck Diameter:
0.444 in
FCEDC - Face Cutting Edge Count:
4
FHA - Flute Helix Angle:
0.0 deg
FHH - Flute Helix Hand:
STRAIGHT
GAMF - Radial Rake Angle:
0.5 deg
GAMP - Axial Rake Angle:
10.0 deg
HAND - Cutting Direction:
Right
ICC - Coolant Thru:
No
Item Quantity:
1
KAPR - Cutting Edge Angle:
95.0 deg
KAPRS - Tool Angle Feed Direction:
95.0 deg
L - Theoretical Cutting Edge Length:
0.02 in
LE - Cutting Edge Effective Length:
0.02 in
LN - Neck Length:
2.5 in
LN1 - Neck Length 1:
2.5 in
LSCN - Clamping Length Minimum:
0.0701 in
LVCatalogue - Catalog Length Value:
2
Neck Angle:
0.0 deg
NOF - Number of Flutes:
4
OAL - Overall Length:
4.5 in
Package Height (inches):
0.709
Package Length (inches):
6.614
Package Weight (lbs):
0.031
Package Width (inches):
0.709
PCEDC - Pheripheral Cutting Edge Count:
4
Product Series:
SN400R
PSIR - Tool Lead Angle:
-5.0 deg
RE - Corner Radius:
0.045 in
RMPX - Maximum Ramping Angle:
1.5 deg
RNA - Axial Runout:
0.00002 in
RNR - Radial Runout:
0.00002 in
RP - Programming Radius:
0.0614 in
ShankType:
Cylindrical
Trademark:
NIAGARA CUTTER
TSCAT - Catalog Tool Shape:
E
UPC Number:
43617030000105
Workpiece Material:
P; H; K; Ti; HRSA
ZEFP - Number of Effective Cutting Edges:
4
ZNP - Number of Peripheral Cutting Edges:
4
Manufactured By:
Niagara
