Part Number: 70892620
/ Vendor ID #: 1150641
MONO CLAMP BORING BAR GX 16
by Ceratizit
Call for Price
Item Sales Info
-
+
Add To Cart
Add To Wishlist
Compare Item
Email
Print
Availability
Manufacturer availability unknown.
Info & Guides
DXF
Product Overview
I20R90-2.0D-GX16-2
MONO CLAMP BORING BAR GX 16 I20R90-2.0D-GX16-2
Category Path
Category:
Turning
Subcategory:
Internal Turning
Subtype:
Indexable Boring Bars
Product Specs
Brand Name:
CERATIZIT
Connection diameter machine side (inch):
0.787
Connection diameter machine side (mm):
20
Cooling:
IC_CENTRAL
cutting depth maximum (inch):
0.217
cutting depth maximum (mm):
5.5
cutting width maximum (inch):
0.148
cutting width maximum (mm):
3.75
cutting width minimum (inch):
0.109
cutting width minimum (mm):
2.76
Execution:
RIGHT
For Groove Inserts:
GX 16-2
functional width (inch):
0.61
functional width (mm):
15.5
ISO Designation:
I20 R 90-2.0D-GX16-2
Item Height (inches):
4.8
Item Length (inches):
1.97
Item Quantity:
1
Item Weight (lbs):
1.022
Item Width (inches):
1.97
Komet Number:
59599 04836
Material group K (H= Main Application, N= Secondar:
0
Material Number:
11348685
minimum bore diameter (inch):
0.984
minimum bore diameter (mm):
25
Overall length (inch):
7.087
overall length (mm):
180
Product Line:
CERATIZIT_PERFORMANCE
Product name:
MONOCLAMP
reduced body diameter length (inch):
1.575
reduced body diameter length (mm):
40
shank height (inch):
0.748
shank height (mm):
19
UPC Number:
4047109289635
Manufacturer Info
Manufactured By:
Ceratizit
