Product Overview

MSS-E25R90-2525L

MODULAR CLAMP MSS HOLDER 90° MSS-E25R90-2525L

Category Path

Category:

Turning

Subcategory:

Groove and Turn and Parting Off

Subtype:

Groove and Turn Indexable Holders

Product Specs

Brand Name:

CERATIZIT

Execution:

RIGHT

For Module:

E25 R/L ...

functional width (inch):

0.984

functional width (mm):

25

head length (inch):

1.102

head length (mm):

28

ISO Designation:

E25 R 90-2525L

Item Height (inches):

5

Item Length (inches):

1.93

Item Quantity:

1

Item Weight (lbs):

1.714

Item Width (inches):

1.93

Material group K (H= Main Application, N= Secondar:

0

Material Number:

217350

overall height (inch):

1.181

overall height (mm):

30

Overall length (inch):

5.512

overall length (mm):

140

overall width (inch):

1.201

overall width (mm):

30.5

Product Line:

CERATIZIT_PERFORMANCE

Product name:

MODULARCLAMP_MSS

shank height (inch):

0.984

shank height (mm):

25

shank width (inch):

0.984

shank width (mm):

25

Manufacturer Info

Manufactured By:

Ceratizit
